ExoFill XP-3000 SeriesFully Automatic Explosion-Proof Raceway Filling System for Solvents, Paints & AsphaltATEX Zone 1 Certified • 40 Pails/Hr • ±0.1% Accuracy • Triple Containment • Industry 4.0
Fully Automatic Explosion-Proof Raceway Filling System for Solvents, Paints & Asphalt
ATEX Zone 1 Certified ? 40 Pails/Hr ? ±0.1% Accuracy ? Triple Containment ? Industry 4.0 Integration
| Parameter | XP-3100 (Standard) | XP-3200X (ATEX Zone 1) | XP-3300H (High-Temp) |
|---|---|---|---|
| Capacity | 30L (±0.1%) | 30L (±0.15%) | 30L (±0.2%) |
| Throughput | 40 Pails/Hr | 36 Pails/Hr | 35 Pails/Hr |
| Material Compatibility | Solvents ? Paints ? Cutback Asphalt ? Emulsions | Explosive Atmospheres | 200°C Hot Applications |
| Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.2% |
| Viscosity Range | 1-2,000,000 cP | 50-800,000 cP | 5,000-5,000,000 cP |
| Explosion Protection | ATEX Zone 1/21 | IECEx Zone 0 | ATEX Cat. 1G/1D |
| Filling Technology | Coriolis Mass Flow + Gear Pump | ATEX Diaphragm Pump | Heated Screw Auger |
| Raceway Design | Single-Sided Linear Conveyor<br>? 1.5m/s Speed<br>? ±0.5mm Positioning<br>? 1,000kg Payload | Pressurized Conveyor | High-Temp Belt (200°C) |
| Containment System | TripleShield?:<br>1. N? Inerting (O?<0.5%)<br>2. -0.8bar Vacuum Hood<br>3. Carbon Adsorption (99.97% VOC) | + Explosion Venting | Vapor Recovery Unit |
| Material Contact | Hastelloy C276 | Zirconium Alloy | Tungsten Carbide (2,200 Hv) |
| Heating System | Jacketed Path (40-80°C) | Same | 200°C ±5°C (Asphalt) |
| Static Control | Ionized Air Curtain<br>10? ions/cm3 ? <0.1kV Charge | SIL-3 Monitoring | Conductive Path (<10? Ω) |
| Changeover Time | <120s (Tool-Free) | <150s | <180s |
| Power | 480V/60Hz, 18kW | 24VDC Ex ia | 480V/60Hz, 22kW |
| Certifications | CE, ISO 9001 | ATEX/IECEx Zone 0 | NFPA 68/77 |
Safety Validation:
| Parameter | Performance | Standard |
|---|---|---|
| O? Concentration | 0.4% ±0.05% | ATEX <8% |
| Vent Efficiency | 99.9% | NFPA 68 >95% |
| Response Time | 0.08s | IECEx <0.5s |
| Technology | Function | Range |
|---|---|---|
| Heated Path | PID Control ±1°C | 40-200°C |
| Shear-Thinning Nozzle | Laser-Engineered Geometry | 1-5,000,000 cP |
| Auto-Viscosity Calibration | In-line Rheometer | ±1% Brookfield |
Solvent & Paint Applications
| Feature | ATEX Solution | Performance |
|---|---|---|
| VOC Control | Activated Carbon Bed | 99.97% Capture |
| Static Dissipation | Ionized Air Curtain (10? ions/cm3) | <0.1kV Surface Charge |
| Color Consistency | In-line Spectrophotometer | ΔE<0.3 (CIELab) |
Asphalt & Bitumen Handling
High-Temp Engineering:
Crystallization Prevention:
| Technology | Effect |
|---|---|
| Continuous Agitation | 0% Separation |
| Thermal Insulation | <0.5°C/min Cooling Rate |
Chemical Processing
| cGMP Feature | Technical Implementation |
|---|---|
| Cleanability | CIP/SIP Validation |
| Data Integrity | 21 CFR Part 11 Audit Trail |
| Material Traceability | RFID/NFC Tracking |
1. AGV Pail Loading → 2. Raceway Conveyor (±0.5mm) → 3. N? Purging (O?<0.3%) → 4. Precision Filling (±0.1%) → 5. Vacuum Hood Retract → 6. Torque-Sealing (50-150 N·m) → 7. Weight/VOC Scan → 8. Palletizing
Cycle Time: 90 seconds/pail
Hazardous Environment Mastery
? Explosion-Safe Architecture: | **Component** | **Certification** | |----------------------|--------------------------| | Electrical System | ATEX Ex ia IIC T4 | | Mechanical Design| EN 1127-1 | | Sensors | SIL-3 Certified | ? Zero-Emission Operation: 1. 99.97% VOC Carbon Adsorption 2. Double Mechanical Seals (API 682) 3. Helium-Leak Verified (<10?? mbar·L/s) ? Industrial 4.0 Integration: - OPC UA/PROFINET Connectivity - Predictive Maintenance AI - Digital Twin Synchronization
? ATEX 2014/34/EU Zone 0/1 ? IECEx IEC 60079-0/1/7/31 ? NFPA 68/69/77 ? API 682
Shell Chemical Distribution Center:
"After implementing XP-3200X:
Output: 22 → 40 Pails/Hr (+82%)
VOC Emissions: ↓99.2% (Carbon Adsorption)
Safety Incidents: 3/year → 0
ROI Period: 9 months"
